Chore-Time LiftPro™ Ventilation Winch for Eggs

• Versatile Applications – Suitable for tunnel doors and a wide range of ventilation systems, including pop-hole doors, Turbo House™ inlets, sidewall inlets, and roll-up rack-style tunnel doors.
• Adaptable – Built to integrate into various facility layouts.

• Custom Electronics and Limit Housing – Purpose-engineered components.
• Slow-Speed Operation – Ensures controlled, consistent movement.
• Full Torque at Start – Delivers dependable performance.
• Positional Feedback with potentiometer.
• Custom Ratio Limit System – Built-in mechanical limits deliver precise positioning every time.
• Manual Override – Permits operation in the absence of power.

• Corrosion-Resistant Construction – Designed and tested for harsh environments; includes zinc-plated mounting.
• Lifting Capacity – Fully configured maximum weight is application-dependent: Single Strap: up to 1348 lbs (611 kg) or Double Strap: up to 2360 lbs (1071 kg).
• Double-Shaft – 2 Brackets with 2 hex head screws each.
• Compact Size – Approximately: 21.25 inches (540 mm) long x 14 inches (356 mm) wide x 12 inches (305 mm) high.

Use with Chore-Time’s CATALYST® Control for a complete package.

LiftPro™ Ventilation Winches have been independently tested and are supported by a one-year warranty.

• Built to Last – UL approved motor and gear box are fitted to a strong, versatile belt.
